Frame

20" aluminum alloy Frame

Motor

250W middle dirven motor ,Low noise,high speed brushless geared DC motor

Tyres

26X1.75 - KENDA

250W for European

Rim

Al alloy double wall and CNC side wall

200W for Australia & New Zealand

Front fork

Al alloy suspension fork -TGS

350W for UAS & Canada

brake

F/DISC brake, R/V brake

Battery

36V/9Ah/10AH/12AH Lithium battery

Head Set

Ahead 1-1/8-NECO

Controller

Sine wave intelligent brushless

Speed gears

SHIMANO 7 speed gears

Display

LCD display

Derailleur

SHIMANO ACERA

Mode

1:1 pedal assistant system(PAS)

Handle bar

Al alloy

��

Pure Electric Run mode by throttle

Stem

Al alloy

Charger

AC 100V-240V, 2 Amps smart charger

Brake lever

Al alloy integrate bell-TEKTRO

Charge time

4-6 hours

Hub

Front quick release

Max speed

25km/h(EU),32km/h(USA & Canada)

Chain

Rust resistant chain Z99 KMC

Range

PAS model Until 120 km

Chain wheel

36T , al alloy crank

��

Max load

E-bike mode 45-55km

Saddle

Black Leather saddle comfortable

120kgs

Seat post

Al alloy with suspension-ZOOM

N.W/G.W

25kgs / 30kgs

Pedal

Al alloy

Carton Size

1450X280X770mm

Light

F/R LED battery lights-SIBANG

Capacity

98pcs/20ft container, 208pcs/40 HQ

   LCD display instrument  Battery; Light Switch, Timer; Assist gear; Average/Maximum Speed; Push aided;  Trip distance/odometer;
